Barbed Wire

Barbed Wire
Barbed Wire
Product Code : S-01
Product Description
Barbed Wire:
Four Barbs of 12 to 18 mm twisted around two line wires having distance of 75 mm + 12 mm, The angle of Barb is 30° - 45 °.

IS - 278 (Both Grades)
Size Variation ± 2.5%

SIZE LENGTH
i.  12 x 12 of 2  ply 18 ft per kg. (± 5%)
     ( 2.5 mm  x  2.5 mm of  ply )
    12 x 12 of ply also available


ii.  12 x 14 of  2 ply 24 ft per kg. (± 5%)
      ( 2.5 x 2 mm of  2 ply )
     12 x 14 of 3 ply also available


iii. 14 x 14 of 2 ply 32 ft per kg. (± 5%)
      ( 2 mm  x  2 mm of  2 ply )
     14 x 14 of 3 ply also available

Barb Distance:
(a)    75 mm ± 12 mm       As per requirement
(b)  150 mm ± 12 mm       As per requirement

Coil Size - 300 to 400 mm
Coil Weight - 30 to 45 Kg.
Packing - Unpacked
Raw-material - M.S. G.I Wire Hot Dip
